Description
Specifications
Topology: Line interactive
Output Power Capacity: 650VA / 390W
Nominal Output Voltage: 230V
Output Voltage Distortion: Less than 5% at full load
Output Frequency (sync to mains): 50/60 Hz +/- 1 Hz
Topology: Line Interactive
Waveform Type: Stepped approximation to a sinewave
Transfer Time: 6ms typical, 10ms maximum
Input
Nominal Input Voltage: 230V
Input Frequency: 50/60 Hz +/- 3 Hz (auto-sensing)
Input Connections: IEC-320 C14
Cord Length: 1.22 meters
Input voltage range for main operations: 180 – 266V
Batteries and Runtime
Battery Type: Maintenance-free, sealed lead-acid battery with suspended electrolyte
Typical Recharge Time: 6 hours
RBC Quantity: 1
Communications and Management
Interface Port(s): USB
Control panel: LED status display with On Line, On Battery, Replace Battery, and Overload indicators
Audible Alarm: Alarm when on battery, distinctive low battery alarm, overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating: 273 Joules
Data Line Protection: RJ-11 Modem/Fax/DSL/10-100 Base-T Ethernet
Physical
Dimensions (H x W x D): 165 x 91 x 284 mm
Weight: 5.9 kg
Environmental
Operating Temperature: 0 – 40°C
Operating Relative Humidity: 0 – 95% non-condensing
Operating Elevation: 0 – 3000 meters
Storage Temperature: -15 – 40°C
Storage Relative Humidity: 0 – 95% non-condensing
Storage Elevation: 0 – 15000 meters
Regulatory Approvals: CE, REACH
